Products Description

The Project	Specifications and parameters	Qualifications
Nominal capacity of☆	100Ah	100A(1.0C) Current discharge
Minimum capacity	100Ah	100A(1.0C) Current discharge
Nominal voltage is ☆	3.20V	25A(0.5C) Current discharge
	≥ 160Wh	25A(0.5C) Current discharge
Discharge Energy (reference)	≥ 157Wh	100A(1.0C) Current discharge
	141Wh/Kg	25A(0.5C) Current discharge
Energy density (reference)	139Wh/Kg	100A(1.0C) Current discharge
	2.0–3.65V	Temperature is T> -5℃
Operating voltage range	2.0–3.65V	-20℃
	1.8–3.65V	T emperature is T ≤ -20℃
Battery internal resistance (1KHz) ☆	≤ 1.5m Ω	New battery 20-50%SOC status, 25℃
Meverage battery internal resistance (1KHz)	~ 0.7mΩ	New battery 20-50%SOC status, 25℃
Shipping capacity	20~50% charging status	25A(0.5C) Current
Operating	0–45℃	Refer to Section 2.2
temperature (charging)	0–45℃	Refer to Section 2.2
Operating	-30–55℃	Refer to Section 2.3
temperature (discharge)	-30–55℃	Refer to Section 2.3
		25 ± 2℃, with splint state, 50A(1.0C)
Cycle life span is	The ≥ 2000 cycle is available	Charge and discharge, the 100%DOD, capacity decays to 80% of the nominal capacity.
Discharge power at room temperature	1300 W(TBD)	25 ± 2℃ 50%SOC 4.0C 10s pulse discharge
The SOC usage scope is recommended	10% - 90%
Core weight is ☆	2000±20g	N.A.
size	27128147mm

CATL, with the full name of Contemporary Amperex Technology Co., Limited, is a leading lithium battery company all over the world located in Ningde, Fujian, China. CATL is the Number One lithium battery manufacturer in China.Now we provide brand new A grade CATL battery cells with reasonable prices and superior services.

Features:

2C Discharge rage
Eco-Friendly
Quick Charge
Low weight, Longer life
Cutoff - Overcharge & Discharge o High-Temperature performance

Specifications

Item	Parameters
Nominal Capacity	120Ah
Nominal Voltage	3.2V
Internal Resistance	≤0.5mΩ
Discharge Cut-off Voltage	2.5V
Standard Charge Current	24A
Charge Voltage	3.65V
Max. Charge Voltage	3.70V
Fast Charge Current	120A
Max. Charge Current	180A
Max. Discharge Current	240A
Weight	2.84Kg
Operating Temperature	Charge	0~45℃
	Discharge	-20~60℃
Storage Temperature	≤1 month	-20~45℃
	≥6 months	-20~35℃

3.2V LiFePO4 Battery Cell
