SPECIFICATIONS

STORAGE CAPACITY

100 ampere hours (Ah). Dakota Lithium batteries provide consistent power for all 100 amp hours. DL LiFePO4 batteries have a flat voltage curve, which means they have a steady power output as the battery discharges. The power output will not dramatically drop like similar sized SLA batteries. You get all the juice down to the last drop.

VOLTAGE

12.8V (Dakota Lithium 12V batteries can be used in series for up to 48V systems)

ENERGY

1280 Watts (Wh)

TERMINALS

F12 Terminals (posts that screw in) with M8 post bolts included. (Max torque 15 ft. lbs.)

SIZE

12.99 in (330mm) L x 6.77 in (172mm) W x 8.66 in (220mm) H. Group 27 equivalent.

WEIGHT

31.9 lbs (14.5Kg). That's 60% lighter than a SLA battery.

GROUP SIZE 27 & 31

BCI Group Number 27 & 31 equivalent / compatible for physical dimensions (L x W x H) & terminal location. Usable deep cycle capacity is much higher (2x) than a lead-acid battery of the same group size. Deep cycle only. Not for starting engines.

LIFECYCLES (BATTERY LIFESPAN)

Up to 80% capacity for 2,000 cycles in recommended conditions. The typical SLA has 500 cycles. Dakota Lithium batteries last so long that the price per use is a fraction of traditional batteries.

OPERATING TEMPERATURE

Ideal for rugged & harsh environments. Much better than SLA or other lithium’s. -20'F min, +120'F max optimal operating temps (battery performs well down to -20'F). Avoid charging below 32'F.

DISCHARGE

100 A max continuous, 200 A max pulse 10 second pulse. The flat discharge voltage curve provides a 75% bigger capacity than a 100Ah SLA battery.

CHARGE

50 A max, 14 V max recommended, 15 V max. Included is a LiFePO4 compatible charger. A SLA charger may work, but will reduce performance and lifespan of the battery.

INCLUDES ACTIVE BMS PROTECTION

Contains a circuit that handles cell balancing, low voltage cutoff, high voltage cutoff, short circuit protection and high temperature protection for increased performance and longer life.

CERTIFICATIONS

All batteries are UN 38 certified. Dakota Lithium's cells are UL1642 certified and have been tested per IEC62133 standards. Meets all US & International regulations for air, ground, train, & marine transport.

CHARGER INCLUDED

10A LiFePO4 charger included

NOT FOR STARTING ENGINES

This is a deep cycle 12v battery. Not designed for starting gasoline engines.
