Product

wall mounted

wall mounted

Product Specification: MOQ: 15pcs or 16pcs Delivery time： 25-35 working days Capacity of supply： About 2 million KVAH each year Color： Color customizable Payment methods : L/C, D/P,T/T, PayPal, Western Union Port: Guangzhou/Shenzhen

GET QUOTE
Items
Specifications
Charge voltage
DC 54.75V
Nominal voltage
48V
Nominal capacity
100Ah
Energy
4.8KWh
Charge current
Standard charge（标准充电）: 0.5C Approx 3 Hour（约 3 小时）
Rapid charge（快速充电）: 1C Approx 1.5 Hour（约 1.5 小时）
Standard Charging method
0.5C.CC (constant current) charge to 58.4V, then CV(constant voltage 58.4V)
charge till charge current decline to 0.05C
Max. charge current
50A
Max. discharge current
100A
Max.Pulse Current
150A（3s）
Discharge cut-off voltage
37.5V
cell & Method
(3.2V100Ah)15S1P
ZHONGYUANIFP105
Operating temperature
Charging(充电):
0°C ~ 45°C
Discharging（放电） : -20°C ~60°C
Storage temperature
- 10°C ~ + 45°C
Battery Weight
Approx.：55 kg
Battery Dimension
580mm*400mm*160mm(W*H*D)
Battery outgoing voltage
48~51V
Thermal sol fire
extinguishing device
NO
